Reliable RF Termination for Low-Power Systems

10 Watt RF Termination Series

Designed for bench testing, calibration, and system protection, Bird’s 10 Watt RF terminations deliver stable impedance, low VSWR, and proven reliability in a compact form.

Why Choose the 10 W Terminations?

Explore 10-T Series Terminations

10-T-series_10W_lightgrey

DC to 4 GHz, Convection-Cooled Dry Terminations

10-T Series

Rugged, compact termination for systems up to 4 GHz. Delivers dependable performance in applications where space, portability, and reliability are critical.

10-18T-series_10W_lightgrey

DC to 18 GHz, Convection-Cooled Dry Terminations

10-18T Series

Ultra-compact termination for precision RF applications up to 18 GHz. Delivers low VSWR and stable performance for high-frequency testing in space-constrained environments.

Compare Models

Find the right RF termination for your application—side-by-side technical specs across Bird’s trusted termination solutions.

Model Number
Frequency Range and VSWR
Connector
Dimensions
Weight
Get Quote/Buy Now
DC to 18 GHz @ 1.05+.05(f)
N (m)
2.2 in x 2.3 in dia
(56 mm x 59 mm dia)
5.9oz (168 g)
DC to 18 GHz @ 1.05+.05(f)
N (f)
2.2 in x 2.3 in dia
(56 mm x 59 mm dia)
5.9oz (168 g)
DC to 1 GHz @ 1.10:1 max
1 to 4 GHz @ 1.15:1 max
BNC (f)
2.2 in x 2.3 in dia
(56 mm x 59 mm dia)
5.9oz (168 g)
DC to 1 GHz @ 1.10:1 max
1 to 4 GHz @ 1.15:1 max
N (f)
2.2 in x 2.3 in dia
(56 mm x 59 mm dia)
5.9oz (168 g)
DC to 1 GHz @ 1.10:1 max
1 to 4 GHz @ 1.15:1 max
N (m)
2.2 in x 2.3 in dia
(56 mm x 59 mm dia)
5.9oz (168 g)
DC to 1 GHz @ 1.10:1 max
1 to 4 GHz @ 1.15:1 max
TNC (m)
2.2 in x 2.3 in dia
(56 mm x 59 mm dia)
5.9oz (168 g)
  Swipe for more

Why RF Pros Trust Bird Terminations

Protect your system. Keep signals clean. When it comes to RF systems, even the smallest components matter. Bird terminations help you keep things running smoothly by preventing signal issues and protecting your gear. They're built to last, easy to trust, and ready for everyday use. Stay focused on the job—Bird has the rest handled.
