4275 Series

20-1000 MHz, THRULINE® RF Signal Samplers


4275 Series, Variable RF Signal Samplers cover the frequency band of 20-1000 MHz with an attenuation range of 35 to 80 dB down from main power. The 4275 signal samplers produces an un-rectified, non-directional sample at the BNC port that is adjustable. Once adjusted, the setting can be locked in place. The main power connectors are Bird® QC type.

Model Selections
Model Connectors
4275 None
4275-020 (N) Male/Female
4275-025 (N) Female/Female
product specifications:
Item No
4275 Series
Item Name
20-1000 MHz, Variable RF Signal Samplers
Power Ratings
1 kW max
Frequency Range
20 - 1000 MHz
Impedance Ω
50
Insertion VSWR
N Connectors
1.1 max. 2 to 512 MHz
1.25 max. 512 to 1000 MHz
Insertion-Loss
0.1 dB max. (2 - 512 MHz)
0.2 dB max.(512 - 1000 MHz)
Temperature Range
-40 to +45° (-40 to +113°)
Connectors
QC Type
Finish
Bright Silver Plate
Size
2-51/64" x 2-7/8" x 1-1/4" (L x W x D)
71 x 73 x 32 mm
Weight
10 oz. (280 g)
